COOK CLEAN Sealing Systems

Comprehensive Emissions Solutions

COOK CLEANTM sealing systems are designed for reciprocating compressor owners and operators who want to exceed emission regulations, maximize natural gas recovery, increase compressor efficiency and reduce downtime and maintenance costs.

Although leakage can be minimized by properly specifying and maintaining the packing case, rings, and rod, the fundamental design of reciprocating compressors makes gas leakage practically unavoidable. Therefore, some type of barrier must be employed to prevent emissions from escaping into the atmosphere.

COOK CLEAN, with its high performance and flexible range of design options, is the industry leader in low-emission sealing systems.

Reduce Fugitive Emissions To Near-Zero Levels

A leading compressor OEM has documented leakage rates near zero to 0.75 SCFM per throw when comparing a COOK CLEAN uncut seal ring (BTUU/CUU) technology against traditional packing technologies, both in controlled R&D environments and from field data.

cook-clean-case-packing-case
Cook CLEAN packing case 3D model - with key features identified

Features for Superior Sealing Performance

  • Spiral-wound end cup gasket made of a highly conformable composite stainless steel/nonmetallic material creates a superior seal between the packing case and compressor.
  • Low emission uncut, or solid, ring technology (BTUU or BTRR) feature a gapless design that eliminates leakage paths.
  • Ultra-smooth lapped sealing surfaces for all rod rings provide excellent surface-to-surface contact for a tight seal.
  • LF Purge Pac® or LF Vent Pac® assemblies use our patented Low Friction technology to extend seal life and simplify maintenance.
  • Recent design enhancements extend the run time of the packing set and provide extra protection to prevent debris from entering the gas vent.

Advantages

  • Reduces fugitive emissions to near zero levels
  • Offers easy, economical conversion for most compressors
  • Provides an effective seal, minimizing purge gas consumption
  • Optional monitoring system allows predictive maintenance

Related Case Studies

cook clean illustration 2 crop

California Gas Producer Hits Emissions Target with COOK CLEAN

To help a major gas producer meet local requirements to reduce cylinder emissions on 90% of its reciprocating compressors, Cook implemented an upgrade to a COOK CLEANTM sealing system – a solution that also significantly improved packing case life.
Read the case study
Solid ring technology - low-emissions rod rings

Solid Ring Technology Yields Solid Results

Packing cases with solid ring technology were installed on two compressors in gas transmission service. After 3,000 hours, measurements confirmed zero vent leakage. Another broad assessment of performance was conducted after 2.5 years.
Read the case study
Compressor packing case collection

Stringent Emission Requirements? Not a Problem

A customer on the West Coast of the United States approached Cook Compression to discuss how they could comply with the increasing emission regulations in the region. The Projects Group assessed the situation and provided solutions that yielded long-term results.
Read the case study
